Claude Code Deep Dive: Core Architecture of a Top-Tier AI Coding Tool

Most articles about Claude Code stop at "install the CLI, post a diff." Drop it into a real team and you quickly see: the core architecture of a top-tier AI coding tool is never just the Agent process in your terminal — it is how Diff, Fact, Context, and Workflow divide labor and close the loop inside the Cloud Mac AI Stack.

This is the L6-Q02 pillar map (L6-Q02): using Claude Code as the entry point to draw the full Stack architecture, five-module onboarding order, and system closed loop. For the operational handbook see L6-Q01 complete handbook; for permission gates see L3 decision opener — this article is the map only.

Claude Code itself: the 10% breakdown (the other 90% is the Stack)

Architecture · Claude Code kernel

Define Claude Code on its own first, then where it sits. It is a terminal coding Agent, not an IDE plugin:

Single Agent loop (may iterate)

  Read CLAUDE.md + repo context
           │
           ▼
  Plan (which files, which commands)
           │
           ▼
  Execute (Write / Edit / Bash / optional MCP Tool)
           │
           ▼
  Verify (your test / lint)
           │
           └──► Output Diff (git-auditable changes)

• Boundaries — CLAUDE.md and permission policy define what it may touch; see handbook · project boundaries
• Extended senses — MCP wires GitHub Issues, CodeGraph, APIs into Context; see MCP triple-connect hub
• vs Cursor — in-editor completion vs cross-file + shell Agent; see vs Cursor

That is L3 only. The "core architecture" organizations actually trust is the Stack map below.

Cloud Mac AI Stack full map (responsibility layers)

Architecture · full site map

This is the site's unified L0–L5 model — return here when reading any topic article. Important: these are responsibility layers, not runtime call order.

Outputs: Inference · Diff · Fact · Context · Workflow

                 ┌──────────────┐
                 │  OpenHands   │  L5 · Workflow (did the whole request finish?)
                 └──────┬───────┘
                        │
                 ┌──────▼───────┐
                 │     MCP      │  L4 · Context (what can the Agent see?)
                 └──────┬───────┘
                        │
                 ┌──────▼───────┐
                 │ Claude Code  │  L3 · Diff (what changed this round?) ← entry
                 └──────┬───────┘
                        │
                 ┌──────▼───────┐
                 │    Ollama    │  L2 · Inference (optional · local private compute)
                 └──────┬───────┘
                        │
                 ┌──────▼───────┐
                 │ GitHub Runner│  L1 · Fact (will the org trust it?)
                 └──────┬───────┘
                        │
                 ┌──────▼───────┐
                 │  Cloud Mac   │  L0 · infrastructure (24/7 macOS node)
                 └──────────────┘

L0 holds compute, L1 holds Fact — only then Diff, Context, and Workflow. However strong Claude Code is, without L1, Diff is just local experimentation.

Five modules (+ foundation): roles and outputs

Architecture · module reference

Workflow (L5) and Fact (L1): OpenHands repeatedly consumes Context, produces Diff, and validates with Fact during a task — not "CI only after Workflow finishes." See OpenHands · output relationships.

Recommended onboarding order: Fact before Diff

Architecture · deployment path

The hype order is usually: Claude Code first → MCP next → CI as an afterthought. We recommend this deployment sequence (different from diagram layer order):

 ① Cloud Mac (L0 foundation)
      │  Always-on macOS · SSH · egress IP
      ▼
 ② GitHub Runner (L1 · Fact)
      │  push → repeatable green/red · workspace isolation
      ▼
 ③ Ollama (L2 · Inference, optional)
      │  local embedding / small models · mind L1/L3 memory
      ▼
 ④ Claude Code (L3 · Diff)
      │  CLAUDE.md · permissions · day-one trial
      ▼
 ⑤ MCP (L4 · Context)
      │  GitHub / CodeGraph / Fetch · least privilege
      ▼
 ⑥ OpenHands (L5 · Workflow)
      │  multi-step issues · agent loop · stacks on L3
      ▼
 ⑦ System closed loop
      delegate → Diff → PR → Runner Fact → review → merge

1. ① L0 — Without a 24/7 macOS node, Runner and Agent fight for laptop RAM; see buy vs rent
2. ② L1 — Give the org trustworthy Fact first; isolation: one job one workspace
3. ③ L2 — Optional; on the same host as Claude Code and Runner see parallel scheduling
4. ④–⑥ — Stack AI after Fact is stable; handbook: L6-Q01
5. ⑦ Closed loop — next section

System closed loop: from Claude Code delegation to green PR

Architecture · closed loop

The last piece of "core architecture" is how data flows back — the Agent cannot live in an isolated terminal:

Human in the loop · L3
  Developer ──delegates──► Claude Code (+ MCP Context)
                        │
                        │  Diff (commit)
                        ▼
                   feature branch / PR
                        │
Machine acceptance · L1        ▼
              GitHub Runner (Fact)
                   xcodebuild / test / lint
                        │
                        ├── red ──► feedback to Agent (Diff ↔ Fact)
                        │
                        └── green ──► human review ──► merge

Optional · L5
  OpenHands clears issue queue overnight ──► same PR + Runner loop

Three hard requirements for a working loop: Runner and Agent environment isolation, PR must pass CI, production secrets never in Agent shell. Production checklist: L6-Q01 · production-grade.

Site-wide link hub: jump by layer

This article is the Stack series map page. Pick an entry by your current blocker:

FAQ

What is Claude Code's core architecture? Terminal Agent loop producing Diff; production-grade also needs CLAUDE.md, MCP Context, and independent Runner Fact.

Must I install Ollama before Claude Code? No. L2 is optional; the diagram shows responsibility layers, not call order.

How is this different from the L6-Q01 handbook? Q01 is the operational spine (install→CI); Q02 is the Stack full map (this article).

Can OpenHands replace Claude Code? No. L5 orchestrates Workflow; L3 pairs to produce Diff — use them stacked.
